23.6inch Electronic Signboard for Desktop Placement and Menu Board Display as Floor Standing Digital Signage
Product Details:
| Place of Origin: | china |
| Brand Name: | CTVS |
| Certification: | CE FCC ROHS 3C |
| Model Number: | ZS-ZA236 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 130USD/PCS |
| Delivery Time: | 5-8 |
| Payment Terms: | T/T |
| Supply Ability: | 100PCS 1week |
|
Detail Information |
|||
| Highlight: | 23.6inch Electronic Signboard,Desktop Placement Digital Display,Menu Board Display Floor Standing Digital Signage |
||
|---|---|---|---|
Product Description
Product specifications
|
ZS-ZA240 |
|||||
|
TFT LCD |
Screen brand |
A+ New Screen |
luminance |
250 cd/m² (Typ.) |
|
|
screen size |
24 inches |
Display scale |
16:9 (H:V) |
||
|
Show area |
535.05×301.68 mm (H×V) |
Viewing angle |
89/89/89/89 (Typ.) (CR≥10) |
||
|
resolution ratio |
1920(RGB)×1080 (FHD) |
contrast ratio |
3000:1 |
||
|
Shell configuration |
Shell material |
metal plate |
|||
|
External dimensions |
540.83*320.63*106.05mm |
packing measurement |
|
||
|
Feature configuration
|
CPU |
A133 quad-core processor with a clock speed of 1.6GHz |
|||
|
running memory |
1G DDR3 |
||||
|
Storage memory |
32G EMMC |
||||
|
decoding resolution |
Supports up to 1080P |
||||
|
operating system |
Android10 |
||||
|
Network support |
Ethernet, supports WiFi, Bluetooth 5.0, and wireless peripheral expansion |
||||
|
Video format |
Supports WMV, AVI, FLV, RM, RMVB, MPEG, TS, MP4, and more |
||||
|
picture format |
Supports BMP, JPEG, PNG, GIF, and more |
||||
|
Interface support |
USB2.0 port (2), HDMI output (1), RJ45 network port (1),3.5mm headphone jack (1) |
||||
|
system support |
Supports USB/T card and network upgrades |
||||
|
Environmental requirements |
Applicable environment |
indoor |
|||
|
working temperature |
-20℃-40℃ |
||||
|
storage temperature |
-20℃~60℃ |
||||
|
Electrical configuration |
working power supply |
AC(100-240)V/50-60HZ |
|||
|
maximum power |
<100W |
||||
|
Complete machine accessories |
Instruction manual, WIFI antenna, power cord, certificate of conformity, warranty card, cardboard box |
||||
|
Warranty Policy |
Free warranty for one year, lifetime cost maintenance |
||||
