Outdoor Floor Standing Digital Signage with 2000 cd/m² Brightness, IP55 Protection Rating, and Android 11 Motherboard
Product Details:
| Place of Origin: | china |
| Brand Name: | CTVS |
| Certification: | CE FCC ROHS 3C |
| Model Number: | ZS-LA430H |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 800-1500USD/pcs |
| Packaging Details: | wooden box |
| Delivery Time: | 5-8work days |
| Payment Terms: | T/T |
| Supply Ability: | 99999 |
|
Detail Information |
|||
| Highlight: | 2000 cd/m² Brightness Outdoor Floor Standing Digital Signage,IP55 Protection Rating Freestanding Digital Display,Android 11 Motherboard Standing LED Advertising Screen |
||
|---|---|---|---|
Product Description
Outdoor Floor Standing Digital Signage
Available in sizes: 32", 43", 49", 55", 65", 75", 86", and 98" displays
Product Overview
High-performance outdoor digital signage featuring industrial-grade components designed for all-weather operation with exceptional durability and advanced functionality.
Key Features
- High-brightness 2000 cd/m² LCD screen with automatic ambient light sensing
- Tempered explosion-proof glass protection
- Android-based motherboard with Wi-Fi and RJ45 connectivity
- Comprehensive protection against lightning, overload, overvoltage, overcurrent, and overheating
- IP55 rated rainproof and dustproof construction
- Remote control capability for individual or group device management
- Full HD 1920x1080 video decoding support
Design & Construction Features
- Elegant Design: Customizable premium shells available in diverse styles
- Timed Backlight: 10 preset time slots for adjustable backlighting
- Smart Temperature Control: Maintains constant dry internal environment to prevent fogging
- Weather Resistance: IP55 protection rating against dust and water ingress
- Durable Housing: Galvanized steel plate with specialized outdoor powder coating
- Longevity: Designed to withstand outdoor use for up to 10 years without fading
Display Module Specifications
- Industrial-grade high-reliability modular design
- High resolution, contrast, and brightness for superior image depth
- Automatic ghost elimination and UV protection
- Energy-saving LCD with green light-sensing technology
- 16.7 million colors for natural, refined imagery
- Wide-temperature LCD panel operating from -40°C to +85°C
- Ultra-long 60,000-hour lifespan with 24/7 operation capability
Electrical & Protection Systems
- Fully galvanized steel shell with IP55 waterproof rating
- Comprehensive electrical protection: leakage current, overload, overvoltage, and lightning protection
- Dual-channel stereo surround amplifier with 2*10W power output
- High-performance cooling fans with automatic temperature control
- 6mm tempered explosion-proof glass
- Automatic ambient light sensing for dynamic brightness adjustment
- Modular design principles for sustainable maintenance
Content Playback Capabilities
Showcase diverse content including images, animations, and videos with interactive touch features to engage audiences and enhance promotional effectiveness.
Smart network system enables remote content streaming across multiple devices nationwide.
Technical Specifications
Construction Components
| Component | Parameter | Specification |
|---|---|---|
| Sheet Metal Housing | Material | 1.5mm SGCC galvanized steel plate |
| Outer Coating | Finish | Zinc-rich base powder with Aksu outdoor plastic powder |
| Durability | Service Life | Over 10 years guaranteed |
| Protection | IP Rating | IP55 with multi-layer filtration system |
| Explosion-proof Glass | Performance | 6mm tempered glass with 3-5* impact resistance of ordinary glass |
Display & Electronics
| Component | Parameter | Specification |
|---|---|---|
| LCD Screen | Luminance | 2000 nits |
| Display | Resolution | HD 1920*1080 |
| Backlight | Technology | LED direct-lit with automatic light sensing |
| Motherboard | Android | 3566 motherboard, 2GB RAM, 16GB storage, Android 11 |
| Power Supply | Brand | Taiwan Mingwei Industrial-grade |
43-inch Model Detailed Specifications
| Parameter | Specification |
|---|---|
| Display Size | 43 inches |
| Display Area | 941*530mm |
| Aspect Ratio | 16:9 |
| Resolution | 1920*1080 |
| Luminance | 2000 cd/m² |
| Contrast Ratio | 1300:1 |
| Viewing Angle | 178° horizontal / 178° vertical |
| CPU | RK3566 |
| Memory | 2G DDR, 16G Flash |
| Interfaces | USB 2.0*4, RJ45*1, HDMI, VGA |
| Protection Rating | IP55 |
| Total Weight | 110KG |
| Cover Glass | 6mm tempered explosion-proof glass |
| Working Temperature | -40°C to +85°C |
| Working Humidity | 5% to 90% |
| Power Supply | 220V, 200W |
| Packing Dimensions | 1930*460*930mm (wooden box) / 1920*480*960mm (wooden frame) |
| Shipping Weight | 125KG |
